BRISBANE 4
Ø127 mm
CEClass IIP20

TECHNICAL SPECIFICATIONS

Material
Aluminium
Lamp
1 COB
Power (Luminaire)
43 W
Lumen (Luminaire)
3954 - 4033 lm
Luminaire luminous efficacy
92 - 94 lm/W
EEC
A++
CCT / CRI
3000K CRI95, 4000K CRI95
MacAdam Ellipse
2 SDCM
Optic
W
Optic Value
55°
Dimming type
DALI, On/Off
Product colors
Black, White
Weight
4.2 kg
Operating temperature
-20 °C to 40 °C
Life time L90B10
90,000 hr
Life time L80B10
100,000 hr
Life time L80B50
140,000 hr

CODE FINDER

Lumen
CCT / CRI
Optic
Optic Value
Dimming type
Product colors
SKU
Lamp
Power
(Lum.)
Lumen
(Lum.)
CCT/CRI
Optic
Optic
Value
Dimming
type
Product
colors
SKU: BRB-95031-W-9530-DA-01
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 3954 lm
CCT/CRI: 3000K CRI95
Optic: W
Optic Value: 55°
Dimming type: DALI
Product colors: Black
SKU: BRB-95031-W-9530-DA-03
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 3954 lm
CCT/CRI: 3000K CRI95
Optic: W
Optic Value: 55°
Dimming type: DALI
Product colors: White
SKU: BRB-95031-W-9530-ND-01
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 3954 lm
CCT/CRI: 3000K CRI95
Optic: W
Optic Value: 55°
Dimming type: On/Off
Product colors: Black
SKU: BRB-95031-W-9530-ND-03
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 3954 lm
CCT/CRI: 3000K CRI95
Optic: W
Optic Value: 55°
Dimming type: On/Off
Product colors: White
SKU: BRB-95031-W-9540-DA-01
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 4033 lm
CCT/CRI: 4000K CRI95
Optic: W
Optic Value: 55°
Dimming type: DALI
Product colors: Black
SKU: BRB-95031-W-9540-DA-03
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 4033 lm
CCT/CRI: 4000K CRI95
Optic: W
Optic Value: 55°
Dimming type: DALI
Product colors: White
SKU: BRB-95031-W-9540-ND-01
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 4033 lm
CCT/CRI: 4000K CRI95
Optic: W
Optic Value: 55°
Dimming type: On/Off
Product colors: Black
SKU: BRB-95031-W-9540-ND-03
Lamp: 1 COB
Power (Lum.): 43 W
Lumen (Lum.): 4033 lm
CCT/CRI: 4000K CRI95
Optic: W
Optic Value: 55°
Dimming type: On/Off
Product colors: White
