NEMO 6NM-50051 (Version 1)
Underwater projectors, floodlights
Without remote driver - Constant voltage (CV) 24 V
TECHNICAL SPECIFICATIONS
Material
Stainless Steel
Light source
1 COB
Power (W)
27 W
Lumen (lm)
2043 - 2151 lm
Efficacy (lm/W)
76 - 80 lm/W
Driver option
Remote driver (not included)
Driver
Constant voltage (CV)
Input voltage
24 VDC
Optic
AS
Optic value
41°x31°
CCT / CRI
3000K CRI80, 4000K CRI80
Bug
B1-U0-G0
ULR
0%
ULOR
0%
CIE flux code nº3
100
Dimming type
On/Off
Product colours
Stainless Steel
Weight
2.9 kg
Operating temperature
-20 °C to 40 °C
Cable
One cable gland supplied with 2 m of 2x1.0 sqmm outdoor cable
Through wiring
Single cable entry
Lens / Reflector / Optic
Clear toughened glass, High-efficiency optical reflector
MacAdam Ellipse
3 SDCM
Lifetime L90B10 (hours)
> 60,500
Lifetime L80B10 (hours)
> 60,500
Lifetime L80B50 (hours)
> 60,500
DOWNLOADS
Family spec sheet
Product spec sheet
Installation manual
Technical drawing
2D - CAD
BIM - IFC
DIALux - ULD
IES
CE documentFor BIM files (Revit - RFA), please check the Variant code
LIGHT EFFECT
Optic
AS (41°x31°)
CODE FINDER
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code: NM-50051-AS-8030-ND-00
Lumen (lm): 2043 lm
Optic: AS
Optic value: 41°x31°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: NM-50051-AS-8040-ND-00
Lumen (lm): 2151 lm
Optic: AS
Optic value: 41°x31°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
