FRAME

FRAMEBollards

Stylish signature seating-bollard with numerous combination options for finishes and lighting. Combine your luminaire and seating needs into one piece of contemporary urban lighting furniture.

German Innovation AwardMicroPRIM™Urban Lighting Furniture
CEClass IIP66IK08

TECHNICAL SPECIFICATIONS

Luminaire Structure

- Die-cast aluminium housing and frame
- Pre-treated before powder coating ensuring high corrosion resistance
- IK08 for the concealed downlight lens and IK10 for the whole body and top casting
- Single cable entry
- Stainless steel fasteners in grade 304 with zinc flake coating (ZFC)
- Durable silicone rubber gasket
- Opal toughened glass
- Integral control gear
- Surge protection 10kV
- Universal power socket & USB (IP66, IK06) is available as an accessory

Feature

LIGMAN's low-power LEDs circular or linear module3000K-4000KRGBWNon-glare luminaire1-10VDALIDMXDMX RDMNon-dimmableClass I with provisions for Class ll

Optic

G / G

PRODUCTS

Power (W)
Optic
Driver option
Class
IP
IK
