LIGMAN LIGHT LINEAR VT 5 VT-20022.

LIGHT LINEAR VT 5VT-20022LIGHT LINEAR VT

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.
Your request was successfully sent.

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.
Your request was successfully sent.
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5Black
LIGHT LINEAR VT 5Dark Grey
LIGHT LINEAR VT 5White
LIGHT LINEAR VT 5Matt Silver
LIGHT LINEAR VT 5Bronze
LIGHT LINEAR VT 5Concrete - Urban
LIGHT LINEAR VT 5Softscape - Urban
LIGHT LINEAR VT 5Stone - Urban
LIGHT LINEAR VT 5Corten - Urban
LIGHT LINEAR VT 5Oak - Woodland
LIGHT LINEAR VT 5Walnut - Woodland
LIGHT LINEAR VT 5Pine - Woodland
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5
LIGHT LINEAR VT 5Black
LIGHT LINEAR VT 5Dark Grey
LIGHT LINEAR VT 5White
LIGHT LINEAR VT 5Matt Silver
LIGHT LINEAR VT 5Bronze
LIGHT LINEAR VT 5Concrete - Urban
LIGHT LINEAR VT 5Softscape - Urban
LIGHT LINEAR VT 5Stone - Urban
LIGHT LINEAR VT 5Corten - Urban
LIGHT LINEAR VT 5Oak - Woodland
LIGHT LINEAR VT 5Walnut - Woodland
LIGHT LINEAR VT 5Pine - Woodland
1 side angular - Supplied with specific square, straight aluminium pole - Height options: 3 - 6 m
CEClass IIP65IK08

Technical information

Material
Aluminium
Light source
2 x 12 LED
Power (W)
81 W
Lumen (lm)
4422 - 6429 lm
Efficacy (lm/W)
55 - 79 lm/W
Driver option
Integral control gear
Driver
Constant current (CC)
Input voltage
220-240 V 50/60 Hz
Optic
T1, T2, T3, T4
Optic value
113°x49°, 130°x45°, 104°x57°, 44°x21°
CCT / CRI
3000K CRI80, 4000K CRI80
Bug
B0-U2-G1, B1-U2-G1
ULR
1%
ULOR
1%
CIE flux code nº3
96, 97, 98
Dimming type
On/Off, 1-10V, DALI
Product colours
Black, Dark Grey, White, Matt Silver, Bronze, Concrete - Urban, Softscape - Urban, Stone - Urban, Corten - Urban, Oak - Woodland, Walnut - Woodland, Pine - Woodland
Weight
25.2 kg
Operating temperature
-20 °C to 50 °C
EPA (m2)
0.078
Cable
One cable gland supplied with 1 m of 3x1.0 sqmm outdoor cable
Through wiring
Single cable entry
Lens / Reflector / Optic
Clear toughened glass, High-efficiency PMMA lens
MacAdam Ellipse
3 SDCM
Lifetime L90B10 (hours)
> 90,000
Lifetime L80B10 (hours)
> 90,000
Lifetime L80B50 (hours)
> 90,000
Variants (On/Off, 1-10V, DALI)
Compatible with EN/ IEC 60598-2-22: Suitable for emergency installations as central supply, non-maintained (Z0)

Light effect

Optic
T1 (113°x49°)
T2 (130°x45°)
T3 (104°x57°)
T4 (44°x21°)

Code finder

Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour

Accessory

Pole (required)
