LIGHTALK 11
Without remote driver - With recessing box - Constant voltage (CV) 24 V - 455 mm - Class III
CEClass IIIIP67IK10

TECHNICAL SPECIFICATIONS

Material
Stainless Steel
Light source
12 LED
Power (W)
16 W
Lumen (lm)
1401 - 1823 lm
Efficacy (lm/W)
88 - 114 lm/W
Driver option
Remote driver (not included)
Driver
Constant voltage (CV)
Input voltage
24 VDC
Optic
VN, N, M, W, E
Optic value
13°, 15°, 26°, 43°, 20° x 35°
CCT / CRI
3000K CRI80, 4000K CRI80
Bug
B2-U1-G0, B3-U1-G0
ULR
0%
ULOR
0%
CIE flux code nº3
100
Dimming type
On/Off
Product colours
Stainless Steel
Weight
2.4 kg
Operating temperature
-20 °C to 40 °C
Cable
Two IP67 connectors supplied with 2x0.2 m of 2x1.0 sqmm outdoor cable
Through wiring
Two cable entries for through wiring
Lens / Reflector / Optic
Clear toughened glass

LIGHT EFFECT

Optic
VN (13°)
N (15°)
M (26°)
W (43°)
E (20° x 35°)

CODE FINDER

Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code: LA-60021-VN-8030-ND-00
Lumen (lm): 1559 lm
Optic: VN
Optic value: 13°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-VN-8040-ND-00
Lumen (lm): 1641 lm
Optic: VN
Optic value: 13°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-N-8030-ND-00
Lumen (lm): 1451 lm
Optic: N
Optic value: 15°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-N-8040-ND-00
Lumen (lm): 1528 lm
Optic: N
Optic value: 15°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-M-8030-ND-00
Lumen (lm): 1732 lm
Optic: M
Optic value: 26°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-M-8040-ND-00
Lumen (lm): 1823 lm
Optic: M
Optic value: 26°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-W-8030-ND-00
Lumen (lm): 1401 lm
Optic: W
Optic value: 43°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-W-8040-ND-00
Lumen (lm): 1475 lm
Optic: W
Optic value: 43°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-E-8030-ND-00
Lumen (lm): 1550 lm
Optic: E
Optic value: 20° x 35°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: LA-60021-E-8040-ND-00
Lumen (lm): 1631 lm
Optic: E
Optic value: 20° x 35°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
