NEON 13ITNO12XXXX1067-ED-HBNEON
EDGE
TECHNICAL SPECIFICATIONS
Power (W)
12 W/m
Driver option
Remote driver (not included)
Driver
Constant voltage (CV)
Input voltage
24V DC
Operating temperature
-20°C ~ +45°C
Optic
160°
Lifetime L80B10 (hours)
> 50,000
Maximum run per power feed
10 m using one feed, 20 m using two feeds
Cutting length
83.3 mm
Control
Constant voltage dimmer (1 Channel)
Dimensions
Width: 11.5 mm × Height: 21 mm
Warranty
5 years
Notes
Colour variance 3000K+/-175K, 4000K+/-275K. Electrical & optical data variance +/-10%.
Minimum bend radius
60 mm
Bend direction
Horizontal
Product spec sheet
Installation manual
Technical drawing
2D - CADVARIANTS
Variant code
Lumen (lm)
Efficacy
CCT / CRI
Variant code: ITNO1230001067-ED-HB
Lumen (lm): 280 lm
Efficacy: lm/W
CCT / CRI: 3000K CRI80
Variant code: ITNO1240001067-ED-HB
Lumen (lm): 320 lm
Efficacy: lm/W
CCT / CRI: 4000K CRI80
