ANNET 1
Without remote box IP-rated - With remote driver - Constant current (CC) 700 mA
CERETILAPClass IIIIP68IK07

TECHNICAL SPECIFICATIONS

Material
Stainless Steel
Light source
3 LED
Power (W)
8 W
Lumen (lm)
506 - 779 lm
Efficacy (lm/W)
63 - 97 lm/W
Driver option
Remote driver (included)
Driver
Constant current (CC)
Input voltage
700 mA, 9 VDC
Optic
N, M, W
Optic value
28°, 32°, 51°
CCT / CRI
2700K CRI80, 3000K CRI80, 4000K CRI80
Bug
B0-U4-G0
ULR
100%
ULOR
100%
Dimming type
On/Off, 1-10V, DALI
Product colours
Stainless Steel
Weight
1.1 kg
Operating temperature
-20 °C to 50 °C
Cable
One cable gland supplied with 2 m of 2x1.0 sqmm outdoor cable
Through wiring
Single cable entry
Lens / Reflector / Optic
Clear toughened glass
MacAdam Ellipse
3 SDCM
Lifetime L90B10 (hours)
> 120,000
Lifetime L80B10 (hours)
> 120,000
Lifetime L80B50 (hours)
> 120,000

LIGHT EFFECT

Optic
N (28°)
M (32°)
W (51°)

CODE FINDER

Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code: AE-50177-N-8027-ND-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 2700K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-N-8030-ND-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-N-8040-ND-00
Lumen (lm): 779 lm
Optic: N
Optic value: 28°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-N-8027-DI-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 2700K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-N-8030-DI-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-N-8040-DI-00
Lumen (lm): 779 lm
Optic: N
Optic value: 28°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-N-8027-DA-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 2700K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-N-8030-DA-00
Lumen (lm): 728 lm
Optic: N
Optic value: 28°
CCT / CRI: 3000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-N-8040-DA-00
Lumen (lm): 779 lm
Optic: N
Optic value: 28°
CCT / CRI: 4000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-M-8027-ND-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 2700K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-M-8030-ND-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-M-8040-ND-00
Lumen (lm): 635 lm
Optic: M
Optic value: 32°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-M-8027-DI-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 2700K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-M-8030-DI-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-M-8040-DI-00
Lumen (lm): 635 lm
Optic: M
Optic value: 32°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-M-8027-DA-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 2700K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-M-8030-DA-00
Lumen (lm): 593 lm
Optic: M
Optic value: 32°
CCT / CRI: 3000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-M-8040-DA-00
Lumen (lm): 635 lm
Optic: M
Optic value: 32°
CCT / CRI: 4000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-W-8027-ND-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 2700K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-W-8030-ND-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-W-8040-ND-00
Lumen (lm): 542 lm
Optic: W
Optic value: 51°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: AE-50177-W-8027-DI-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 2700K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-W-8030-DI-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-W-8040-DI-00
Lumen (lm): 542 lm
Optic: W
Optic value: 51°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: AE-50177-W-8027-DA-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 2700K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-W-8030-DA-00
Lumen (lm): 506 lm
Optic: W
Optic value: 51°
CCT / CRI: 3000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
Variant code: AE-50177-W-8040-DA-00
Lumen (lm): 542 lm
Optic: W
Optic value: 51°
CCT / CRI: 4000K CRI80
Dimming type: DALI
Product colour: Stainless Steel
