LIGMAN BORNHOLM 4 BOH-60031.

BORNHOLM 4BOH-60031

(Version 1)

Recessed underwater projectors

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.
Your request was successfully sent.

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.
Your request was successfully sent.
BORNHOLM 4
Without remote box IP-rated - With remote driver / recessing box - Constant current (CC) 2670 mA
CERETILAPClass IIIIP68IK07

Technical information

Material
Stainless Steel
Light source
16 LED
Power (W)
39 W
Lumen (lm)
3172 - 4416 lm
Efficacy (lm/W)
81 - 113 lm/W
Driver option
Remote driver (included)
Driver
Constant current (CC)
Input voltage
2670 mA, 12 VDC
Optic
N, M, W, VW, E
Optic value
11°, 17°, 32°, 71°x58°, 43°x11°
CCT / CRI
3000K CRI80, 4000K CRI80
Bug
B2-U0-G0, B3-U0-G0
ULR
<1%
ULOR
<1%
CIE flux code nº3
100
Dimming type
On/Off, 1-10V
Product colours
Stainless Steel
Weight
3.6 kg
Operating temperature
-20 °C to 40 °C
Cable
One cable gland supplied with 2 m of 2x1.0 sqmm outdoor cable
Through wiring
Single cable entry
Lens / Reflector / Optic
Clear toughened glass
MacAdam Ellipse
3 SDCM
Lifetime L90B10 (hours)
> 120,000
Lifetime L80B10 (hours)
> 120,000
Lifetime L80B50 (hours)
> 120,000

Light effect

Optic
N (11°)
M (17°)
W (32°)
VW (71°x58°)
E (43°x11°)

Code finder

Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code
Lumen (lm)
Optic
Optic value
CCT / CRI
Dimming type
Product colour
Variant code: BOH-60031-N-8030-ND-00
Lumen (lm): 4130 lm
Optic: N
Optic value: 11°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-N-8040-ND-00
Lumen (lm): 4416 lm
Optic: N
Optic value: 11°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-N-8030-DI-00
Lumen (lm): 4130 lm
Optic: N
Optic value: 11°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-N-8040-DI-00
Lumen (lm): 4416 lm
Optic: N
Optic value: 11°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-M-8030-ND-00
Lumen (lm): 3469 lm
Optic: M
Optic value: 17°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-M-8040-ND-00
Lumen (lm): 3709 lm
Optic: M
Optic value: 17°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-M-8030-DI-00
Lumen (lm): 3469 lm
Optic: M
Optic value: 17°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-M-8040-DI-00
Lumen (lm): 3709 lm
Optic: M
Optic value: 17°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-W-8030-ND-00
Lumen (lm): 3518 lm
Optic: W
Optic value: 32°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-W-8040-ND-00
Lumen (lm): 3761 lm
Optic: W
Optic value: 32°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-W-8030-DI-00
Lumen (lm): 3518 lm
Optic: W
Optic value: 32°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-W-8040-DI-00
Lumen (lm): 3761 lm
Optic: W
Optic value: 32°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-VW-8030-ND-00
Lumen (lm): 3172 lm
Optic: VW
Optic value: 71°x58°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-VW-8040-ND-00
Lumen (lm): 3392 lm
Optic: VW
Optic value: 71°x58°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-VW-8030-DI-00
Lumen (lm): 3172 lm
Optic: VW
Optic value: 71°x58°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-VW-8040-DI-00
Lumen (lm): 3392 lm
Optic: VW
Optic value: 71°x58°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-E-8030-ND-00
Lumen (lm): 3671 lm
Optic: E
Optic value: 43°x11°
CCT / CRI: 3000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-E-8040-ND-00
Lumen (lm): 3925 lm
Optic: E
Optic value: 43°x11°
CCT / CRI: 4000K CRI80
Dimming type: On/Off
Product colour: Stainless Steel
Variant code: BOH-60031-E-8030-DI-00
Lumen (lm): 3671 lm
Optic: E
Optic value: 43°x11°
CCT / CRI: 3000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel
Variant code: BOH-60031-E-8040-DI-00
Lumen (lm): 3925 lm
Optic: E
Optic value: 43°x11°
CCT / CRI: 4000K CRI80
Dimming type: 1-10V
Product colour: Stainless Steel

Accessory
