PATCHI 1PAT-30011
(Version 1)
PATCHI

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.

Your request was successfully sent.

Send us an E-Mail or use the contact form:

I have read the privacy policy and agree to the processing of my data *

The fields marked with an * must be correctly filled.

Your request was successfully sent.

Without remote driver - Constant voltage (CV) 24 V - Class III - RGBW dynamic programming - 32 addresses/channels - 43.4x57.8 mm - 1000 mm

TECHNICAL SPECIFICATIONS

Material

Aluminium

Light source

48 LED

Power (W)

13 W

Lumen (lm)

381 - 388 lm

Efficacy (lm/W)

32 lm/W

Driver option

Remote driver (not included)

Driver

Constant voltage (CV)

Input voltage

24 VDC

Optic

EW

Optic value

130°

CCT / CRI

RGBW30, RGBW40

Dimming type

DMX

Product colours

Matt Silver

Weight

0.8 kg

Operating temperature

-20 °C to 40 °C

Through wiring

Two cable entries for through wiring

Lens / Reflector / Optic

Opal PMMA curved diffuser

DOWNLOADS

Family spec sheet

Product spec sheet

Installation manual

Technical drawing

For BIM files (Revit - RFA), please check the Variant code

LIGHT EFFECT

Optic

EW (130°)

CODE FINDER

Lumen (lm)

Optic

Optic value

CCT / CRI

Dimming type

Product colour

Variant code

Lumen (lm)

Optic

Optic value

CCT / CRI

Dimming type

Product colour

Variant code: PAT-30011-EW-30-DMX-05

Lumen (lm): 381 lm

Optic: EW

Optic value: 130°

CCT / CRI: RGBW30

Dimming type: DMX

Product colour: Matt Silver

Variant code: PAT-30011-EW-40-DMX-05

Lumen (lm): 388 lm

Optic: EW

Optic value: 130°

CCT / CRI: RGBW40

Dimming type: DMX

Product colour: Matt Silver
